300W Solar Mono Panel Kit Solar Panel High Efficient Monocrystalline Solar Panel

Model
NK-PL300W
Power Tolerance (Positive)
5%
Module Efficiency STC
19.18%
Maximum System Voltage
1000V
Series Fuse Rating
15A
Cell Type
Monocrystalline 156.75 x 156.75 mm
Cell Number
72 (6 x 12)
Dimensions (mm)
990 x 1580 x 35
Weight (Kgs)
16.50

Produt Details

PRODUCT: 300 Watt Monocrystalline Solar Panel.

MODEL: NK-PL300W

SELLING POINT OF 300W Mono Solar Panel:

(1) New upgrades design with 72 cells mono crystalline module.

(2) 300W power output range.

(3) 0/+5% positive power tolerance.

(4) Low-light performance.

(5) Maximized energy harvest.

(6) Withstanding harsh environment.

(7) High module conversion efficiency (up to 19.18%), through innovative manufacturing technology.

(8) 100% EL test before and after lamination, and finished products EL test, providing higher quality assurance.

(9) Certified to withstand: wind load (2400 pascal) and snow load (5400 pascal).

300W solar panel

300W Mono Solar Panel FUNCTION FEATURES

PID Resistant	High Efficiency	Severe Weather Resilience
Advanced cell technology and qualified materials lead to high resistance to PID.	High module conversion efficiency (up to 19.18%), through innovative manufacturing technology.	Certified to withstand: wind load (2400 pascal) and snow load (5400 pascal).
Low-Light Performance	Higher Quality Assurance	Maximized Energy Harvest
Advanced glass and solar cell surface texturing allow for excellent performance in low-light environments.	100% EL test before and after lamination, and finished products EL test, providing higher quality assurance.	Impedance matching technology eliminates mismatch loses, more power from each module bin.

LINEAR PERFORMANCE WARRANTY: 10-year product warranty & 25-year linear power warranty.

300W-solar-panel-details

300W solar panel specifications

MODEL	NK-PL300W
ELECTRICAL CHARACTERISTICS
	STC	NOCT
Maximum Power (Pmax)	300W	223W
Maximum Power Voltage (Vmpp)	36.20V	33.80V
Maximum Power Current (Impp)	8.30A	6.66A
Open Circuit Voltage (Voc)	45.00V	42.30V
Short Circuit Current (Isc)	9.01A	7.24A
Power Tolerance (Positive)	5%
Module Efficiency STC	19.18%
Operating Temperature Range	Minus 40 degrees celsius to 85 degrees celsius
Maximum System Voltage	1000V
Series Fuse Rating	15A
Temperature Coefficient of Pmax	Minus 0.44% / degrees celsius
Temperature Coefficient of Voc	Minus 0.33% / degrees celsius
Temperature Coefficient of Isc	0.055% / degrees celsius
MECHANICAL CHARACTERISTICS
Cell Type	Monocrystalline156.75 x 156.75 mm
Cell Number	72 (6x12)
Dimensions (mm)	990 x 1580 x 35
Weight (Kgs)	16.50
Front Glass	3.2 mm, high transmission, low iron, tempered glass
Frame Type	Anodized aluminium alloy
Junction Box Protection Class	IP 67 rated
Connector Type	MC4

300W Mono Solar Panel PROJECT SERVICE PROCESS

(1) PROJECT CONSULTATION.	(2) THE PROJECT SURVEY.	(3) PROJECT DESIGN.
Product introduction, process explanation, investment budget analysis.	Engineers site roof survey, load measurement, shielding analysis, electrical building path planning.	According to the survey results, the optimal system design scheme and grid connection scheme are formulated to escort the high-quality power station.
(4) APPLICATION.	(5) PROVIDE COMPLETE EQUIPMENT.	(6) OVERSEAS OPERATION, MAINTENANCE AND SERVICE GUARANTEE.
Responsible for preparing the application materials and connecting to the network.	According to the design to provide photovoltaic panel, inverter, bracket and other complete set of material equipment.	Professional construction, grid acceptance, operation and maintenance, intimate after-sales service.

Namkoo Project Service Process

ABOUT NAMKOO

Namkoo Group is an international high-technology and fast growing group company, we specializing in R&D, manufactures on grid and off grid solar power system, hybrid solar storage system, mono solar panel, poly solar panel, flexible solar panel, Shingled & HJT Solar Panel, solar inverter & battery, and other solar applications. With more than 18 years solar experience, Namkoo is aiming to become “Your Best Collaborate Solar Manufacturer”.

Apart from the traditional solar panel, battery, solar power system and solar pump system products, we have researched and offered successful advanced solar application including BIPV solar projects, solar carport charger station, IOT + solar products like A.I. solar bus station and A.I. PV waste sorting kiosk, etc.

solar power system and solar panel manufacturing details

Namkoo has distributed 97 patents. The distribution of invention patents accounted for 29%, and the issued patents accounted for 65%. 14 software Copyrights have been distributed, of which 100% have been issued.

The patent application covers waterproof, corner, flexible, controllable temperature, fault identification, adjustable, intelligent, high power, high density and other functional and technical highlights, covering the core photovoltaic power station, photovoltaic vehicle, photovoltaic bracket, photovoltaic tile, photovoltaic building, sun room, cloud broadcasting, charging pile, storage device, photovoltaic street lamps and other products. Involving multiple grid, PERC, buckle, mechanical plug type and other key technology, process.

The 14 software Copyrights form the intellectual property protection of core system technologies such as photovoltaic power station monitoring system, cloud broadcasting system, atmospheric environment monitoring system, motor operation monitoring system, water quality monitoring system, intelligent water system, intelligent fire protection system, intelligent bus station air monitoring system.
